Prozessor 1 auswählen
Prozessor 2 auswählen
ASUS TUF Gaming GeForce RTX 3070
Videokarte 2 auswählen
User rating
star star star star star
Freigegeben
Q4/2020
ASUS TUF Gaming GeForce RTX 3070

Grafikkarte ASUS TUF Gaming GeForce RTX 3070, Spezifikationen und Benchmarks

650 Platz in der Gesamtwertung Grafikkarten (GPU)!
Eine detaillierte Übersicht über die Grafikkarte ASUS TUF Gaming GeForce RTX 3070, deren Produktionsdatum im Q4/2020 begann. Hier werden alle technischen Spezifikationen sowie Leistungsergebnisse in Form von Schätzungen moderner Benchmarks präsentiert. Starttaktfrequenz 1.500 GHz. Die Grafikkarte unterstützt GDDR6 und hält 8 GB Videospeicher an Bord. Die TDP beträgt {{Watt}}. Wir empfehlen, die GPU mit anderen Modellen auf unserer Website zu vergleichen, um die beste Leistung zu ermitteln.

Specifications

Technische Daten
GPU
  • Based on
    NVIDIA GeForce RTX 3070
  • Execution Units
    46
  • GPU Chip
    GA104-300-A1
  • Render Output Einheiten
    96
  • Shader
    5888
  • Textur Einheiten
    184
Speicher
  • Memory Bandwidth
    448 GB/s
  • Memory Bus
    256 bit
  • Speichergröße
    8 GB
  • Memory Speed (legacy frequency label)
    1750 MHz
  • Speicher Typ
    GDDR6
Taktfrequenz
  • Grundfrequenz
    1500 MHz
  • Maximale Frequenz
    1755 MHz + 2%
  • Game Clock
    1725 MHz
  • Übertaktung
    Ja
Energieverbrauch
  • Maximum Junction Temperature
    93 °C
  • TDP
    220 W
  • TDP (up)
    250 W+ 4 %
Kühlung
  • Kühler-Typ
    Air cooling
  • Ventilator-Typ
    Axial
  • Fan 1
    3 x 95 mm
  • Fan 2
    —
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    43-45 dB
Konnektivität
  • DisplayPort Ports
    3 × DisplayPort 1.4a
  • DVI-Ports
    —
  • HDCP Version
    2.3
  • HDMI-Ports
    2 × HDMI 2.1
  • Max. Anzeigen
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    2 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
Funktionen
  • DirectX
    12_2
  • DLSS / FSR
    Ja
  • LED
    ASUS Aura Sync
  • Max. Auflösung
    7680 × 4320
  • Raytracing
    Ja
Unterstützte Videocodecs
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode
  • VP9
    Decode
Abmessungen
  • Höhe
    127 mm
  • Länge
    300 mm
  • Slot Size
    3 PCIe-Slots
  • Weight
    —
  • Width
    52 mm
Zusätzliche Daten
  • Spezifikation
    data sheet
  • Launch Price (historical)
    729 $
  • Part Number
    TUF-RTX3070-8G-GAMING
  • Process Technology
    8 nm
  • Datum der Veröffentlichung
    Q4/2020
Positionen in allen Ranglisten

Gemeinsame Standpunkte ASUS TUF Gaming GeForce RTX 3070 GPU in gängigen Benchmarks, zum Vergleich mit anderen Modellen.

  • FP32 Performance (Single-precision TFLOPS)
    560 place
  • 3DMark Benchmark
    632 place
  • Battlefield 5
    608 place
  • Shadow of the Tomb Raider
    671 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    413 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    373 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    576 place
  • Crypto-Mining Vertcoin Hashrate (MH/s)
    195 place

Benchmarks (tests)

Leistungstests GPU

Published results: 53

3DMark graphics tests

Each row is a separate graphics subtest. Scores are not game FPS.

Test and settingsASUS TUF Gaming GeForce RTX 3070
3DMark – Time Spy — Graphics Score / DirectX 12 13854 points Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 7950X3DOS: Windows 11Graphics API: DirectX 12HVCI: enabledApplication version unreported
3DMark – Steel Nomad — Steel Nomad Score / DirectX 12 3170 points Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBOS: Windows 11Graphics API: DirectX 12HVCI: enabledApplication version unreported

Game frame rates

Each row uses one game, resolution, test suite and graphics mode.

Test and settingsASUS TUF Gaming GeForce RTX 3070
Gaming suite 2021 / Assassin's Creed Valhalla / 1920x1080 / Extrem-Hoch-Preset / Rendering unreported 76.1 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Borderlands 3 / 1920x1080 / Badass-Preset / Rendering unreported 125.4 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 11Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Call of Duty Black Ops Cold War / 1920x1080 / Maximale Grafikdetails, SSR Niedrig / Rendering unreported 130.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Control / 1920x1080 / Hoch-Preset / Rendering unreported 110.9 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Cyberpunk 2077 / 1920x1080 / Ultra-Preset / Rendering unreported 76.9 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Death Stranding / 1920x1080 / Sehr-Hoch-Preset / Rendering unreported 181.8 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Dirt 5 / 1920x1080 / Ultrahoch-Preset / Rendering unreported 113.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Doom Eternal / 1920x1080 / Ultra-Albtraum-Preset / Rendering unreported 252.9 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / F1 2020 / 1920x1080 / Ultrahoch-Preset, ASSAO, SRT Schatten Ein / Rendering unreported 170.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Gears 5 / 1920x1080 / Ultra-Preset, Animation Beste, Dynamische Schatten, Volumetrischer Nebel, Oberflächenreflexionen und Umgebungsverdeckung Wahnsinnig, SSGI Strahlen 32, kein VRS / Rendering unreported 86.7 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Hitman 3 / 1920x1080 / Maximale Grafikdetails, kein VRS / Rendering unreported 150.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Horizon Zero Dawn / 1920x1080 / Ultimative-Qualität-Preset / Rendering unreported 95.6 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
More tests: 39
Test and settingsASUS TUF Gaming GeForce RTX 3070
Gaming suite 2021 / Mafia: Definitive Edition / 1920x1080 / Hoch-Preset / Rendering unreported 125.7 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Red Dead Redemption 2 / 1920x1080 / Höchstes Grafik-Preset / Rendering unreported 76.6 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Serious Sam 4 / 1920x1080 / Ultra-Preset, maximierte GPU-Speed-Einstellungen / Rendering unreported 77.5 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Star Wars: Squadrons / 1920x1080 / 125 % Auflösung, Ultra-Preset, Umgebungsverdeckung Ultra / 125% / RT off 182.4 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Watch Dogs: Legion / 1920x1080 / Ultra-Preset / Rendering unreported 72.8 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Assassin's Creed Valhalla / 2560x1440 / Extrem-Hoch-Preset / Rendering unreported 62.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Borderlands 3 / 2560x1440 / Badass-Preset / Rendering unreported 91.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 11Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Call of Duty Black Ops Cold War / 2560x1440 / Maximale Grafikdetails, SSR Niedrig / Rendering unreported 94.7 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Control / 2560x1440 / Hoch-Preset / Rendering unreported 73.7 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Cyberpunk 2077 / 2560x1440 / Ultra-Preset / Rendering unreported 52.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Death Stranding / 2560x1440 / Sehr-Hoch-Preset / Rendering unreported 135.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Dirt 5 / 2560x1440 / Ultrahoch-Preset / Rendering unreported 91.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Doom Eternal / 2560x1440 / Ultra-Albtraum-Preset / Rendering unreported 200.1 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / F1 2020 / 2560x1440 / Ultrahoch-Preset, ASSAO, SRT Schatten Ein / Rendering unreported 124 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Gears 5 / 2560x1440 / Ultra-Preset, Animation Beste, Dynamische Schatten, Volumetrischer Nebel, Oberflächenreflexionen und Umgebungsverdeckung Wahnsinnig, SSGI Strahlen 32, kein VRS / Rendering unreported 62.4 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Hitman 3 / 2560x1440 / Maximale Grafikdetails, kein VRS / Rendering unreported 108.1 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Horizon Zero Dawn / 2560x1440 / Ultimative-Qualität-Preset / Rendering unreported 78.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Mafia: Definitive Edition / 2560x1440 / Hoch-Preset / Rendering unreported 89.8 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Red Dead Redemption 2 / 2560x1440 / Höchstes Grafik-Preset / Rendering unreported 65.9 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Serious Sam 4 / 2560x1440 / Ultra-Preset, maximierte GPU-Speed-Einstellungen / Rendering unreported 66.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Star Wars: Squadrons / 2560x1440 / 125 % Auflösung, Ultra-Preset, Umgebungsverdeckung Ultra / 125% / RT off 128.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Watch Dogs: Legion / 2560x1440 / Ultra-Preset / Rendering unreported 59.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Assassin's Creed Valhalla / 3840x2160 / Extrem-Hoch-Preset / Rendering unreported 40.5 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Borderlands 3 / 3840x2160 / Badass-Preset / Rendering unreported 49.7 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 11Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Call of Duty Black Ops Cold War / 3840x2160 / Maximale Grafikdetails, SSR Niedrig / Rendering unreported 51.9 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Control / 3840x2160 / Mittel-Preset / Rendering unreported 48.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 11Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Cyberpunk 2077 / 3840x2160 / Mittel-Preset / Rendering unreported 40.7 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Death Stranding / 3840x2160 / Sehr-Hoch-Preset / Rendering unreported 80 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Dirt 5 / 3840x2160 / Ultrahoch-Preset / Rendering unreported 59.6 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Doom Eternal / 3840x2160 / Ultra-Albtraum-Preset / Rendering unreported 100.8 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / F1 2020 / 3840x2160 / Ultrahoch-Preset, ASSAO, SRT Schatten Ein / Rendering unreported 64.8 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Gears 5 / 3840x2160 / Ultra-Preset, kein VRS / Rendering unreported 48.3 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Hitman 3 / 3840x2160 / Maximale Grafikdetails, kein VRS / Rendering unreported 64.6 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Horizon Zero Dawn / 3840x2160 / Ultimative-Qualität-Preset / Rendering unreported 49.5 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Mafia: Definitive Edition / 3840x2160 / Hoch-Preset / Rendering unreported 50.1 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Red Dead Redemption 2 / 3840x2160 / Höchstes Grafik-Preset / Rendering unreported 43.1 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Serious Sam 4 / 3840x2160 / Ultra-Preset, 16×AF / Rendering unreported 60.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: VulkanDriver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Star Wars: Squadrons / 3840x2160 / 125 % Auflösung, Ultra-Preset, Umgebungsverdeckung Ultra / 125% / RT off 71.4 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled
Gaming suite 2021 / Watch Dogs: Legion / 3840x2160 / Ultra-Preset / Rendering unreported 39.2 FPS Base GPU test: Nvidia GeForce RTX 3070 VRAM: 8 GBTest CPU: AMD Ryzen 9 5950XSystem RAM: 4 × 8 GB G.Skill TridentZ, DDR4-3600 16-16-16-32-1T, optimierte Sekundär-Timings, Single-RankOS: Windows 10 20H2Graphics API: DirectX 12Driver: 461.40Resizable BAR: disabled

A base GPU test is a reference for cards using that GPU and the same memory capacity. Board overclocking, cooling and power limits can change the result.

Vergleichen Sie die Ergebnisse beliebter Benchmarks ASUS TUF Gaming GeForce RTX 3070 mit anderen Grafikkarten, um die tatsächliche Geschwindigkeit des Grafikprozessors bei der Verarbeitung von Inhalten zu verstehen.

Zu den Tests gehören die Arbeit mit Fließkommazahlen, das Erstellen von 3D-Modellen und das Schürfen von Kryptowährungen.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archived results. The original measurement method and test conditions have not been verified.

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 ist eine 32-Bit-Gleitkommaberechnung für die GPU, die für 3D-Spiele erforderlich ist.

Higher values are better in this metric.

20.67 TFLOPS
ASUS TUF Gaming GeForce RTX 3070
20.74 TFLOPS
20.74 TFLOPS
20.67 TFLOPS
3DMark Benchmark
3DMark ist für Gamer, Übertakter und Systementwickler gedacht, die das Beste aus ihrer Hardware herausholen wollen.

Higher values are better in this metric.

13960
ASUS TUF Gaming GeForce RTX 3070
14005
14005
13960
Battlefield 5
Battlefield 5 ist ein realistisches Spiel, mit einem eingebauten Benchmark, sehr geeignet als Test für Grafikkarten.

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider hat einen eingebauten Benchmark, der auf der Crystal Dynamics Foundation Engine basiert.

Higher values are better in this metric.

Crypto-Mining Ethereum Hashrate (MH/s)
Ethash ist ein Algorithmus für das Mining der Kryptowährung Ethereum, der die GPU-Leistung optimal ausnutzt.

Higher values are better in this metric.

Crypto-Mining Ergo Hashrate (MH/s)
Der Autolykos-Algorithmus, auf dem die Kryptowährung Ergo basiert, ermöglicht es, nicht nur moderne Grafikprozessoren für das Mining zu verwenden, sondern auch die vorherige Generation von Grafikprozessoren.

Higher values are better in this metric.

161 MH/s
ASUS TUF Gaming GeForce RTX 3070
162 MH/s
162 MH/s
161 MH/s
Crypto-Mining Ravencoin Hashrate (MH/s)
Hashrate-Mining der Kryptowährung Ravencoin mit dem KawPoW-Algorithmus ist auf modernen Grafikkarten am schnellsten.

Higher values are better in this metric.

Crypto-Mining Vertcoin Hashrate (MH/s)
Die Kryptowährung VertCoin kann sowohl auf Nvidia- als auch auf AMD-Grafikprozessoren gemined werden und ist interessant, weil sie perfekt auf alten Grafikprozessoren wie GTX1050, R9 290 und sogar GTX970 gemined werden kann.

Higher values are better in this metric.

1.22 MH/s
ASUS TUF Gaming GeForce RTX 3070
1.23 MH/s
1.23 MH/s
1.22 MH/s

Synonyme

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

ASUS Turbo GeForce RTX 3070 ASUS Turbo GeForce RTX 3070 Siehe
MSI GeForce RTX 3070 Ventus 2X 8G OC MSI GeForce RTX 3070 Ventus 2X 8G OC Siehe
MSI GeForce RTX 3070 Ventus 3X 8G OC MSI GeForce RTX 3070 Ventus 3X 8G OC Siehe
ZOTAC Gaming GeForce RTX 3070 Twin Edge OC ZOTAC Gaming GeForce RTX 3070 Twin Edge OC Siehe
ASUS ROG Strix GeForce RTX 3070 White ASUS ROG Strix GeForce RTX 3070 White Siehe
ASUS ROG Strix GeForce RTX 3070 ASUS ROG Strix GeForce RTX 3070 Siehe
ASUS KO GeForce RTX 3070 ASUS KO GeForce RTX 3070 Siehe
ASUS GeForce RTX 3070 Noctua Edition ASUS GeForce RTX 3070 Noctua Edition Siehe

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
