AMD Ryzen 7 9800X3D — Specifications and Blender benchmarks

Specifications Benchmarks Synonyms

Specifications

Technical data

CPU generation and family

Family
Ryzen
Form Factor
Desktops / Boxed Processor
Name
AMD Ryzen 7 9800X3D
Segment
Desktop
Series
Ryzen 9000 Series

CPU Cores and Base Frequency

Base Frequency
4.7 GHz
CPU Cores
8
CPU Threads
16
Max. Boost Clock
5.2 GHz
Overclocking
Yes
Turbo Frequency (1 Core)
5.2 GHz

Internal Graphics

GPU Frequency
2200 MHz
GPU name
AMD Radeon Graphics
Graphics Cores
2

Memory & PCIe

Memory channels
2
Memory type
DDR5
PCIe
PCIe 5.0

Thermal Management

Default TDP
120 W
Maximum Operating Temperature
95 °C
TDP (PL1 / PBP, legacy combined label)
120 W

Technical details

Architecture
Zen 5
Codename
Granite Ridge AM5
I/O die process
TSMC 6nm FinFET
L2-Cache
8 MB
L3-Cache
96 MB
Official source
https://www.amd.com/en/products/processors/desktops/ryzen/9000-series/amd-ryzen-7-9800x3d.html
Release date
2024-11-07
Socket
AM5
Technology
TSMC 4nm FinFET
Verification scope
Explicit manufacturer fields refreshed; other original historical fields retained, not all reverified. Partial composite conflicts are preserved.
Verified on
2026-09-30

Positions in all rankings

Common positions AMD Ryzen 7 9800X3D CPU in popular benchmarks, for comparison with other models.

No data

Blender Open Data

Official median of community submissions; higher is better. Blender versions, operating systems and compute backends remain separate.

Blender 5.2.0 / CPU / Linux: 386.396267 samples/min submissions: 30; snapshot: 2026-09-30 Official source
Blender 5.2.0 / CPU / Windows: 366.580728 samples/min submissions: 135; snapshot: 2026-09-30 Official source

Snapshot date is the retrieval date, not the measurement date. Individual dates, RAM, drivers and power limits are unknown. This aggregates different user systems; it is not a test of a specific partner board and is excluded from the legacy composite index.

Results with primary test sources

Published measurements are separate from the archived index. Incomplete conditions and unknown run counts do not support ranking positions or calculated performance differences.

Test	Result	Source / retrieved
Cinebench R15 / multi-core	3647 points	Notebookcheck 2026-09-30 UTC
Cinebench R15 / single-core	328 points	Notebookcheck 2026-09-30 UTC
Cinebench R20 / multi-core	9057 points	Notebookcheck 2026-09-30 UTC
Cinebench R20 / single-core	818 points	Notebookcheck 2026-09-30 UTC
Cinebench R23 / multi-core	23230 points	Notebookcheck 2026-09-30 UTC
Cinebench R23 / single-core	2080 points	Notebookcheck 2026-09-30 UTC

Benchmarks

Performance tests CPU

No comparable legacy benchmark results are available.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Cinebench R23 · Cinebench R20 · Cinebench R15 · Cinebench 2026 · RandomX benchmark

Comparable benchmark results are required to suggest performance alternatives.

PL1 is the sustained processor power limit; PL2 is the short-term turbo power limit. They are not measured performance or efficiency.

The values are used to select the optimal cooling system and power supply.
